Mesin Cetak Flexo 8 Warna

Keseluruhan mesin menggunakan sistem kawalan servo terkini dari Jerman dan setiap unit percetakan digerakkan oleh motor servo bebas. Terdapat 23 motor servo secara keseluruhan untuk mesin 8warna yang memastikan pendaftaran yang tepat semasa larian berkelajuan tinggi.

Hantar pertanyaan

Penghantaran Cepat
Jaminan kualiti
Perkhidmatan Pelanggan 24/7

pengenalan produk

ZJR-350/450/650 Flexo Printing Machine

Ciri-ciri utama

1. The whole machine adopts the latest servo control system from Germany and each printing unit is driven by independent servo motor. There are 23 servo motors in total for 8color machine which

memastikan pendaftaran yang tepat semasa larian berkelajuan tinggi.

2. The printing roller adopts sleeve system which is light, easy, convenient and fast to change. This type of design is largely improve the printing quality and reduce the maintenance

3. Fast and easy Pressure adjustment of printing or ink transferring: Printing roller run by bearer, it's not necessary to adjust the pressure when change the roller, or at most ne adjust for special job.

4. Anvil roller equips with water chiller, it's good for lm material as well.

5.Suitable for printing variety lm material, such as PET, OPP, CPP, PP and so on.

Automatik Flexographic Label Printing Machine
Model	Ecoo-ZJR350	Ecoo-ZJR450	Ecoo-ZJR650
Maks. Kelajuan pencetakan	180m/min	180m/min	180m/min
Warna cetakan	4-12 warna	4-12 warna	4-12 warna
Maks. lebar web	360mm	470mm	670mm
Maks. lebar percetakan	350mm	450mm	650mm
Maks. diameter melonggarkan	900mm	900mm	1000mm
Maks. diameter gulung semula	900mm	900mm	1000mm
Panjang percetakan	241.3-603.25mm	241.3-603.25mm	304-730.25mm
Dimensions (LWH)	10.83m x 1.56m x 1.52m	10.83m x 1.68m x 1.52m	10.0m1.88m1.56m
Dimensions (LWH)	for 8colors, 3 die cutting stations	for 8colors, 3 die cutting stations	Tiada stesen pemotong mati
